Part case · Metal 3D Printing

Metal AM aerospace lattice panel sample

Aerospace lattice panel / skin sample — for discussing printable lattice skins and which edges need solid frames for fastening.

Metal additive aerospace lattice panel sample
Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK part case — brand remains 3DWK; not a BLT storefront listing.
  1. 01

    Lattice-panel notes

    Open cells need flush paths and solid fastening frames.

    • Call cell size class on the RFQ
  2. 02

    Honesty bar

    No claimed weight-reduction percentages or aircraft brands on this page.

Typical specification

Starting points for this part

Process
Metal powder-bed fusion
Form
Lattice panel / skin sample
Features
Open lattice field
Post
Frame / edge finish TBD
Note
Geometry sample
Metal additive aerospace lattice panel sample
Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK part case — brand remains 3DWK; not a BLT storefront listing.
