Part example · Metal 3D Printing

Metal AM flanged cylinder batch on build plate

3DWK example (authorized photo). Incomplete parameters marked Example · to be confirmed / 「示例、待确认」. Batch of identical flanged cylinders still on a build plate, illustrating nested metal AM production of repeat mounts or housings.

Batch of metal 3D printed flanged cylinders on a build plate
Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK example page — brand remains 3DWK; not a BLT storefront listing.
  1. 01

    Batch framing

    Nesting identical solids on one plate is common for brackets and mounts. Orientation affects support volume and flange flatness.

    Spec sheet mindset

    Call flange flatness and hole position only where needed; leave non-critical skins as-built if cosmetics allow.

    Example · to be confirmed — not a production lot record.

  2. 02

    RFQ checklist

    Alloy, quantity intent, which faces must be machined, and any marking requirements.

    Example · to be confirmed / 「示例、待确认」

Typical specification

Starting points for this part

Process
Metal AM batch build Example · to be confirmed / 「示例、待确认」
Material
SS or Al alloy Example · to be confirmed / 「示例、待确认」
Form
Cylinder + square flange Example · to be confirmed / 「示例、待确认」
Features
Corner bolt holes Example · to be confirmed / 「示例、待确认」
Post
Plate separation, optional CNC Example · to be confirmed / 「示例、待确认」
Batch of metal 3D printed flanged cylinders on a build plate
Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK example page — brand remains 3DWK; not a BLT storefront listing.

Next step

Have a similar part?

Upload CAD and drawings. An engineer reviews materials, tolerances and finish before pricing.
