Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK example page — brand remains 3DWK; not a BLT storefront listing.
ProcessMetal AMExample · to be confirmed
MaterialNi superalloy (example)Example · to be confirmed
JacketLattice over solid linerExample · to be confirmed
BoreMay need flow-face finishExample · to be confirmed
Lattice jacket cautions
Lattice around a flow liner can save mass but traps powder if cells are closed. Design escape holes and show them on the drawing.
- Transition lattice struts gradually into solid walls
- Keep the flow bore free of support scars if fluid performance matters
No pressure or temperature ratings are claimed on this example page.
Next step
Have a similar part?
Upload CAD and drawings. An engineer reviews materials, tolerances and finish before pricing.
