Part example · Metal 3D Printing
Metal AM conformal mold insert (shoe)
Shoe-shaped mold insert example suggesting conformal cooling channels — channel layout must be confirmed on your CAD.
Typical specification
Key values
| Item | Typical value | Note |
|---|---|---|
| Process | Metal AM tool insert | Example · to be confirmed |
| Material | Maraging / H13-class (example) | Example · to be confirmed |
| Cooling | Conformal channels TBD | Example · to be confirmed |
| Cavity | Polish / texture TBD | Example · to be confirmed |
Tooling angle
Conformal cooling can follow the cavity, but channel diameter and powder-removal paths must be designed deliberately.
- Show water inlets/outlets on the drawing
- Separate cavity steel requirements from AM blank notes
Example insert — not a production mold quote.
Next step
Have a similar part?
Upload CAD and drawings. An engineer reviews materials, tolerances and finish before pricing.
