Part example · Metal 3D Printing
Metal AM radial-pattern mold insert
3DWK example (authorized photo). Incomplete parameters marked Example · to be confirmed / 「示例、待确认」. Square mold-insert style block with a radial sunburst cavity example, useful for talking through patterned tooling and corner mounting ears.
Typical specification
Key values
| Item | Typical value | Note |
|---|---|---|
| Process | Metal AM mold insert | Example · to be confirmed / 「示例、待确认」 |
| Material | Tool steel | Example · to be confirmed / 「示例、待确认」 |
| Cavity | Radial / sunburst pattern | Example · to be confirmed / 「示例、待确认」 |
| Mounts | Corner ears with holes | Example · to be confirmed / 「示例、待确认」 |
| Cooling | Channels TBD | Example · to be confirmed / 「示例、待确认」 |
Spec sheet
Patterned cavities need clear polish or texture callouts and a powder-removal plan if internal channels exist.
- Machine mounting ears if positional accuracy matters
- State resin or process intent when requesting a quote
Example · to be confirmed — not a production mold quote.
Example · to be confirmed / 「示例、待确认」
